Viking Access Systems
Viking Solar ECU Electronic Control Unit for G5 Solar
SKU
VA-ECUMSNXSLR2
$ 1,165.00
- Ships in 1–2 daysMost products, from order receipt
- Gates & arms varyMay need extra manufacturing lead time
- Viking Access SystemsAuthorized distributor
- Real tech support321-250-2500
- UL 325 compliant
- Two monitoring inputs w/ up to 4 devices per input
- On board display
- Built-in voltmeter
- Lightning strike protection
- 12V Solar panel input
- 12V Battery charger
- Solar panel switch
- Battery switch
- Sleep mode
- Adaptive motor control
- Adjustable speed control
- Anti-tailgating feature
- Built-in 3A solar charge regulator
- Big box can hold a 35Ah battery
- Enclosure: Aluminum construction, powder coated, post mount options built-in, pre-punched holes for conduit, padlock latch, IP54 certified ingress protection
| Compatible Models | G5 Solar |
|---|---|
| Operating Voltage | 24VDC |
| Main Power Fuse | 4A Timed |
| Power Source | SOLAR 12VDC |
| Accessory Power | 24VDC - 750mA |
| Power Consumption Single - Sleep | 19mA |
| Power Consumption Dual - Sleep | 23mA |
| Motor Current (Typical) | 2.0A |
| Operating Temperature | -4°F (-20°C) to 160°F (71°C) |
| Dimensions Standard Box (L x D x H) | 16.375 x 6.25 x 17.875 in |
| Dimensions Big Box (L x D x H) | 18.75 x 8.125 x 18.2 in |
