FAAC 455D 115VAC/220VAC Control Board for Swing Gate Operators
Regular price
$ 944.00
Regular price
Sale price
$ 944.00
Unit price
per
Couldn't load pickup availability
FAAC 455D — 115VAC/220VAC Control Board for Swing Gate Operators. Part of the FAAC Automated Systems for Swing-leaf Gates - High Voltage range.
Features
- Operates a single leaf or bi-parting gate
- Programmable opening and closing slow down
- Eight different function logics
- Built in closing timer
- Fail safe function for photocells
- Opening and closing delays selectable for overlapping gates
- Electrical thrust force adjustable
- Interface board with: loop detector rack, shadow loop connector, magnetic lock/solenoid control, pluggable terminals
- Enclosure: aluminum construction, powder coated, post mount options built in, pre-punched holes for conduit
Technical Specifications
| Input voltage | 115 VAC (+10% -6%) or 230 VAC (+6% -10%) |
| Input power | 10 W |
| Motor max. load | 800 W |
| Accessory max. load | 500 mA |
| Maglock / Solenoid max load | 2500 mA |
| Operating Temperature | -4°F - 131°F (-20°C - +55°C) |
| Dimensions overall (L x D x H) | 16.375 x 6.25 x 17.875 in |
| Weight | 17 lb |
| Protection class | IP54 |
| Number of operating logics | 8 |
| Protection Fuses | 2 |
Models & Part Numbers
| Configuration | Voltage | Part No. | Shipping Wt (approx) | List Price |
|---|---|---|---|---|
| Control Board Replacement (pre ANSI/CAN/UL325:2017 ED.7) | 115V | 790919 | $944 | |
| Control Board Replacement (pre ANSI/CAN/UL325:2017 ED.7) | 220V | 790926 | $944 | |
| Control Board Replacement | 115V | 790944 | $924 | |
| Control Board Replacement | 220V | 790945 | $924 | |
| 455D with 18 x 16 in. metal enclosure | 115V | 455D115.1 | 17 lb | $1,548 |
| 455D with 18 x 16 in. metal enclosure | 220V | 455D220.1 | 17 lb | $1,548 |
Accessories & Compatible Components
| Description | Part No. | List Price |
|---|---|---|
| Empty Enclosure E024U/455D | 5350.1 | $725 |
